Model: M03-1017
36 volt 500 watt electric scooter motor with #25 chain sprocket.
Type: Brush
Voltage: 36 Volt DC
Rated Speed: 2500-3000 Rpm
Rated Current: 18.3 Amp
Sprocket: #25 Chain Sprocket
Output: 500 Watts
Sprocket: Removable Bolt Sprocket
Case Length: 5-5/16" (135 mm)
Case Diameter: 4-1/4" (108 mm)
Drive Shaft Length: 1" (25 mm)
Drive Shaft Diameter: 5/16" (8 mm)
Mounting Hole Distance: 3-3/4" (95 mm)
